动力速沉器

High-speed Sedimentation Machine

速沉器是集混凝、沉降及深床过滤于一体的新型水处理设备。

速沉器的沉降方式于静态沉降不同，是带压状态下的动态沉降，实现了深床过滤与沉降的有效结合，带压状态下污泥可以即时有效地排出，从而大大提高了过滤效果。

High-speed Sedimentation Machine is a new water treatment device which combines coagulation, sediment and deep bed filtration together.

The sediment method adopted is different from static sediment, which is a dynamic sediment under pressure effectively combining the deep bed filtration and sediment. In this way, the sludge can be timely and effectively discharged with pressure so that the filtration efficiency can be highly improved.

技术特点

n 带压全封闭，从源头上解决曝氧腐蚀问题；

n 抗负荷冲击能力强，出水水质好，工况稳定；

n 高效组合，停留时间短，占地面积小

n 加药量小，运行成本低；

n 结构紧凑，体积小，易于安装；

n 自动化程度高，操作方便，使用寿命长。

运行参数

进水压力： 0.2-0.4MPa

水力损失：0.1MPa

来水水质：油含量﹤100mg/L

悬浮物：无特殊要求

出水水质：油含量﹤10mg/

悬浮物﹤10mg/L

Technical Characteristics

§ Fully enclosed with pressure, solve the problem of oxygen aeration corrosion from its source;

§ Strong impulsion load resistance, high quality discharged water, stable operation status;

§ Effective combination, short duration, less land occupation;

§ Less usage of chemicals, low operation cost;

§ Compact structure, small dimension, easy installation;

§ Highly-automation, easy operation, long service life.

Parameter

§ Water inlet pressure: 0.2-0.4MPa

§ Hydraulic loss: 0.1MPa

§ Intake water quality: Oil <100mg/L SS: unlimited

§ Effluent quality: Oil <10mg/L SS: <10mg/L
